S32205 Seamless Pipe

Category:

Stainless Steel Pipe/Tube

ASTM A790 Duplex Steel UNS S32205 Pipe Size : 1/2"NB TO 12 "NB IN.
Seamless Pipe & Tube Size : 1/2” NB – 8” NB.
Welded Pipe & Tube Size : 6” NB – 24” NB.

Inquiry

Send Email To Me

Keyword :

Stainless Steel Pipe/Tube

Product introduction

Trade name	Duplex Steel S32205 Seamless Pipe
Duplex Steel 2205 Pipes Standard	AISI, DIN, EN, GB, JIS, ASTM, ASME
2205 Duplex Steel Seamless Pipe Dimensions	ANSI/ASME B36.19, B36.10
ASTM A790 Duplex Steel Seamless Pipe OD	6.00 mm OD up to 250 mm OD, Sizes up to 12” NB
Wall Thickness	0.3mm – 50 mm
Duplex Steel Seamless Pipe Available Sizes	3/8″ NB to 12″ NB Schedule 10s 1/8″ NB to 12″ NB Schedule 40s 1/8″ NB to 12″ NB Schedule 80s 4″ NB to 8″ NB Schedule 120 1/2″ NB to 10″ NB Schedule 160 1/2″ NB to 6″ NB Schedule XXS
Pipe Schedule	SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS
A790 Duplex Steel Seamless Pipe Finish & Surface Treatment	Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF, NO.1, NO.4, 2B, BA, HL, 8K, Mirror finish,etc
Form	Round, Square, Hollow, Rectangular, Hydraulic, Coiled, Straight Pipes, “U” Shape, Pan Cake Coils etc.
Length	Single Random, Double Random, Standard & Cut length
End	Plain End, Beveled End, Treaded.
Seamless Pipe Manufacturing Techniques	Seamless / ERW/ EFW / Welded / Fabricated / CDW / DOM / CEW Pipes
Duplex Steel Seamless Pipes Marking	All Pipes are marked as follows: Grade, Standard, OD, Thickness, Length, Heat No. (Or according to the customer’s request.)
Delivery Time	7-15 working days as usual, It will based on the detailed order quantity.
Payment Terms	Paypal, Western Union, T/T (Telegraphic Transfer or Wire Transfer), L/C or Trade Assurance 30% deposit & balance before shipping
Free Sample	Yes if we have in stock

Technical data

Duplex UNS S32205 Pipe & Tubing Equivalent Grades :

STANDARD	WERKSTOFF NR.	UNS	ASTM	AFNOR (NF)
Duplex 2205	1.4462	S32205	2205	Z2 CND 22.06

Duplex UNS S32205 Pipe Chemical Composition / Chemistry :

Element	Min	Max
C	–	1
N	–	0.03
P	–	0.02
Si	–	2
Mn	3	3.5
Mo	22	23
Fe	–	0.03
cr	4.5	6.5
s	0.14	0.2

1. The main and typical steel steel:
Serial number	Steel	(AISI) Typical steel
1	Austenite	301, 310S, 304, 304L, 304H, 316, 316L, 316Ti,317, 317L, 321, 321H, 347H, 904L.Etc
2	Duplex	S31803, S32205, S31500, S31750,S31760, S31900, S32304
3	Incoloy	800, 800H, 800HT, 825, 901, 925, 926
4	Inconel	600, 601, 625, 718
5	Monel	400, K500

2. Main production standard:
Serial number	Standard type	Production standard
Stainless steel seamless tubes (cold, cold, light)	EN	EN 10216-5, EN 10216-2
	DIN	DIN 17456, DIN 17458
	ASTM/ASME	A213, A269, A511, A789, A790, A335, A376，SA213, SA312, SA789, SA790, SA335, SA376，SB161, SB163, SB167, SB338, SB668, SB677
	JIS	JIS G3459, G3463
	GB	GB/T 14975, T14976, GB13296, GB5310,GB9948

3. Product specifications:
Serial number	Product	Specifications
1	Cold drawn pipe	Outside diameter(OD) φ6 - φ1016 mm, (WT) φ1 - φ50.01mm
2	Cold rolled tube	Outside diameter(OD) φ16 - φ325 mm, (WT) φ1 - φ30mm

O.D(mm)	THK(mm)	O.D(mm)	THK(mm)	O.D(mm)	THK(mm)
6	0.5-1.5	45	2.0-15.0	159	3.0-32.0
8	0.5-2.0	48		168	3.0-50.0
10	0.8-3.0	51		180
12	0.8-3.0	54		194
14	0.8-4.0	57		219
16		60		245	3.5-50.0
17		63		273	3.5-50.0
18	0.9-7.0	68	2.5-22.0 2.5-25.0	325	4.5-50.0
19		70		351
20		73		356
21		76		377
22		83		406	5.0-55.0
25	1.0-8.0	89		426	5.0-55.0
27	1.0-8.0	95		450	7.0-55.0
30	1.3-8.0	102		457
32	1.5-10.0	108		480
34		114		508
35		127	3.0-32.0	530
38		133		559	9.0-55.0
40		140		610
42	2.0-11.0	146		660
42	2.0-11.0	152		711

Grade	C	Si	Mn	P	S	Ni	Cr	Mo
201	≤0 .15	≤0 .75	5. 5-7. 5	≤0.06	≤ 0.03	3.5 -5.5	16 .0 -18.0	-
202	≤0 .15	≤1.0	7.5-10.0	≤0.06	≤ 0.03	4.0-6.0	17.0-19.0	-
301	≤0 .15	≤1.0	≤2.0	≤0.045	≤ 0.03	6.0-8.0	16.0-18.0	-
302	≤0 .15	≤1.0	≤2.0	≤0.035	≤ 0.03	8.0-10.0	17.0-19.0	-
304	≤0 .008	≤1.0	≤2.0	≤0.045	≤ 0.03	8.0-10.5	18.0-20.0	-
304L	≤0.03	≤1.0	≤2.0	≤0.035	≤ 0.03	9.0-13.0	18.0-20.0	-
309S	≤0.08	≤1.0	≤2.0	≤0.045	≤ 0.03	12.0-15.0	22.0-24.0	-
310S	≤0.08	≤1.5	≤2.0	≤0.035	≤ 0.03	19.0-22.0	24.0-26.0	-
316	≤0.08	≤1.0	≤2.0	≤0.045	≤ 0.03	10.0-14.0	16.0-18.0	2.0-3.0
316L	≤0.03	≤1.0	≤2.0	≤0.045	≤ 0.03	12.0 - 15.0	16 .0 -1 8.0	2.0 -3.0
321	≤0.08	≤1.0	≤2.0	≤0.035	≤ 0.03	9.0 - 13 .0	17.0 -19.0	-
630	≤0.07	≤1.0	≤1.0	≤0.035	≤ 0.035	3.0-5.0	15.5-17.5	-
631	≤0.09	≤1.0	≤1.0	≤0.030	≤0.035	6.50-7.75	16.0-18.0	-
904L	≤2.0	≤0.045	≤1.0	≤0.035	-	23.0·28.0	19.0-23.0	4.0-5.0
2205	≤0.03	≤1.0	≤2.0	≤0.030	≤0.02	4.5-6.5	22.0-23.0	3.0-3.5
2507	≤0.03	≤0.8	≤1.2	≤0.035	≤0.02	6.0-8.0	24.0-26.0	3.0-5.0
2520	≤0.08	≤1.5	≤2.0	≤0.045	≤0.03	0.19 -0. 22	0.24 -0.26	-
410	≤0.15	≤1.0	≤1.0	≤0.035	≤0.03	-	11.5-13.5	-
430	≤0.1 2	≤0.75	≤1.0	≤ 0.040	≤0.03	≤0.60	16.0 -18.0	-

Stainless Steel(austenitic type)
USA	Germany		CHINA	Japan	Great Britain		France	Italy	Spain	Sweden
AISI/SAE	W.-nr.	DIN	GB	JIS	BS	EN	AFNOR	UNI	UNE	SS
304L	1.4306	X2CrNi1911	0Cr19Ni10	SUS340L	304S11	-	Z2CN18.10	X2CrNi18.11	-	2352
304	1.435	X5CrNi189	0Cr18Ni9	SUS304	304S11	58E	Z6CN18.09	X5CrNi1810	F.3551/F.3541/F.3504	2332
303	1.4305	X12CrNiS188	1Cr18Ni9MoZr	SUS303	303S21	58M	Z10CNF18.09	X10CrNiS18.09	F.3508	2346
301	1.431	X12CrNi177	Cr17Ni7	SUS301	-	-	Z12CN17.07	X12CrNi1707	F.3517	2331
316	1.4401	X5CrNiMo1810	0Cr17Ni11Mo2	SUSU316	316S16	58J	Z6CND17.11	X5CrNiMo1712	F.3543	2347
316LN	1.4429	X2CrNiMoN1813	0Cr17Ni13Mo	SUSU316LN	-	-	Z2CND17.13	-	-	2375
316LN	1.4435	X2CrNiMo1812	0Cr27Ni12Mo3	SCS16/SUS316L	316S13	-	Z2CND17.12	X2CrNiMo1712	-	2353
317L	1.4438	X2CrNiMo1816	0Cr19Ni13Mo	SUS317L	317S12	-	Z2CND19.15	X2CrNiMo1816	-	2367
321	1.4541	X10CrNiTi189	1Cr18Ni9Ti	SUS321	321S12	58B	Z6CNT18.10	X6CrNiTi1811	F.3553/F.3523	2337
347	1.455	X10CrNiNb189	1Cr18Ni11Nb	SUS347	347S17	58F	Z6CNNb18.10	X6CrNiNb1811	F.3552/F.3524	2338
316Ti	1.4571	X10CrNiMoTi1810	Cr18Ni12Mo2T	-	320S17	58J	Z6CNDT17.12	X6CrNiMoTi1712	F.3535	2350
309	1.4828	X15CrNiSi2012	1Cr23Ni13	SUH309	309S24	-	Z15CNS20.12	X6CrNi2520	-	-
310S	1.4845	S12CrNi2521	0Cr25Ni20	SUH310	310S24	-	Z12CN2520	X6CrNi2520	F.331	2361
321	1.4878	X12CrNiti189	1Cr18Ni9Ti	SUS321	321S32	58B,58C	Z6CNT18.12B	X6CrNiTi1811	F.3523	-

Stainless Steel(Ferrite type/Martensitic type)
USA	Germany		CHINA	Japan	Great Britain		France	Italy	Spain	Sweden
AISI/SAE	W.-nr.	DIN	GB	JIS	BS	EN	AFNOR	UNI	UNE	SS
403	1.4	X7Cr13	0Cr13/1Cr12	SUS403	403S17	-	Z6C13	X6Cr13	F.3110	2301
410	1.4006	X10Cr13	1Cr13	SUS410	410S21	56A	Z10C14	X12Cr13	F.3401	2302
430	1.4016	X8Cr17	1Cr17	SUS430	430S15	60	Z8C17	X8Cr17	F.3113	2320
-	1.4034	X46Cr13	4Cr13	SUS420J2	420S45	56D	Z40CM/Z38C13M	X40Cr14	F.3405	2304
431	1.4057	X22CrNi17	1Cr17Ni2	SUS431	431S29	57	Z15CNi6.02	X16CrNi16	F.3427	2321
430F	1.4104	X12CrMoS17	Y1Cr17	SUS430F	-	-	Z10CF17	X10CrS17	F.3117	2383
434	1.4113	X6CrMo17	1Cr17Mo	SUS434	434S17	-	Z8CD17.01	X8CrMo17	-	2325
405	1.4724	X10CrA113	0Cr13AI	SUS405	403S17	-	Z10C13	X10CrA112	F.311	-
430	1.4742	X10CrA118	Cr17	SUS430	430S15	60	Z10CAS18	X8Cr17	F.3113	-
EV8	1.4871	X53CrMnNiN219	5Cr2Mn9Ni4N	SUH35	349S54	-	Z52CMN21.09	X53CrMnNiN219	-	-
